C中的扇形（）函数-yiteyi-C++库

头文件显示图形。h包含扇形（）函数，该函数绘制并填充一个椭圆形饼图切片，其中（x，y）为圆心，（s_角，e_角）为起始角和结束角，（x_半径，y_半径）为扇形的x和y半径。 语法：

null

void sector(int x, int y, int s_angle,
           int e_angle, int x_radius,
                        int y_radius);

where,
(x, y) is center of the sector.
(s_angle, e_angle) are starting
and ending angles.
(x_radius, y_radius) are x and y
radius of sector.

例如：

Input : x = 200, y = 200, s_angle = 0,
         e_angle = 150, x_radius = 50,
         y_radius = 65
Output :

Input : x = 200, y = 200, s_angle = 30,
        e_angle = 120, x_radius = 90,
        y_radius = 85
Output :

下面是sector（）函数的实现：

                     // C Implementation for sector()
                     #include <graphics.h>

                     // driver code
                     int                               main()
                     {
                                         // gm is Graphics mode which is
                                         // a computer display mode that
                                         // generates image using pixels.
                                         // DETECT is a macro defined in
                                         // "graphics.h" header file
                                         int                               gd = DETECT, gm;

                                         // initgraph initializes the
                                         // graphics system by loading a
                                         // graphics driver from disk
                                         initgraph(&gd, &gm,                               ""                               );

                                         // sector function
                                         sector(200, 200, 0, 150, 50, 65);

                                         getch();

                                         // closegraph function closes the
                                         // graphics mode and deallocates
                                         // all memory allocated by
                                         // graphics system .
                                         closegraph();

                                         return                               0;
                     }

输出：
