矩形（） 用于绘制矩形。绘制矩形需要左上角和右下角的坐标。left指定左上角的X坐标，top指定左上角的Y坐标，right指定右下角的X坐标，bottom指定右下角的Y坐标。 语法：

null

rectangle(int left, int top, int right, int bottom);

例如：

Input : left = 150, top = 250, right = 450, bottom = 350;
Output :


Input : left = 150, top = 150, right = 450, bottom = 450;
Output :

推荐：请尝试你的方法 {IDE} 首先，在进入解决方案之前。

下面是矩形函数的实现：

                     // C program to draw a rectangle
                     #include <graphics.h>

                     // Driver code
                     int                               main()
                     {
                                         // gm is Graphics mode which is a computer display
                                         // mode that generates image using pixels.
                                         // DETECT is a macro defined in "graphics.h" header file
                                         int                               gd = DETECT, gm;

                                         // location of left, top, right, bottom
                                         int                               left = 150, top = 150;
                                         int                               right = 450, bottom = 450;

                                         // initgraph initializes the graphics system
                                         // by loading a graphics driver from disk
                                         initgraph(&gd, &gm,                               ""                               );

                                         // rectangle function
                                         rectangle(left, top, right, bottom);

                                         getch();

                                         // closegraph function closes the graphics
                                         // mode and deallocates all memory allocated
                                         // by graphics system .
                                         closegraph();

                                         return                               0;
                     }

输出：
